Modicon TSX Premium TSXPSY1610 Power Supply Unit

The Modicon TSX Premium TSXPSY1610 Power Supply Unit is a DC power supply module designed for the Modicon Premium PLC automation platform. The legacy TSX PSY 1610 reference is specified as a non-isolated 24V DC power supply module, with an input voltage range of 19.2 to 30V DC and typical total useful output power of 30W.

Schneider Electric documentation identifies the corresponding TSXPSY1610M reference as a Modicon Premium power supply module with 1500mA input current and 30W secondary power. The TSXPSY1610M documentation is useful for identifying the specifications and application of this legacy Premium PLC power supply family.

ZE MARINE supplies used and refurbished industrial and marine automation equipment, subject to current stock and condition.

Modicon TSXPSY1610 Specifications

The legacy TSX PSY 1610 documentation specifies 24V DC nominal input, 19.2–30V DC operating limits, ≤1.5A nominal input current and 30W typical total useful power. Its 5V DC output is rated at 3A nominal, with 15W typical power.

TSX Premium PLC Power Supply

The TSXPSY1610 is part of the power-supply range used with the Modicon Premium automation platform. Schneider Electric’s Premium documentation explains that each TSX RKY rack is equipped with a suitable power supply module, with the required module selected according to the power consumption of the modules installed in the rack.

This makes the TSXPSY1610 relevant when maintaining existing Modicon Premium PLC installations where the original rack power supply needs replacement.

Potential applications include:

• Modicon Premium PLC systems
• Industrial automation control panels
• Marine automation systems using Modicon Premium PLCs
• PLC rack power supply replacement
• Industrial control system maintenance
• Automation panel refurbishment
• Replacement of obsolete Premium PLC components

24V DC Input and 5V DC Output

The TSX PSY 1610 uses a 24V DC nominal supply. Its documented input voltage limits are 19.2 to 30V DC, with a typical total useful output power of 30W.

The module provides a 5V DC output rated at 3A nominal, corresponding to approximately 15W typical power. A 24V relay output is also specified at 0.6A nominal.

These characteristics make the module suitable for compatible Modicon Premium rack configurations where the installed PLC modules require the appropriate internal supply voltages.

Compatibility with Modicon Premium PLC Systems

Before purchasing a replacement TSXPSY1610 Power Supply Unit, compatibility should be checked against the existing PLC rack and module configuration.

Please verify:

• Existing power supply reference
• TSX Premium PLC rack model
• Module configuration
• Input supply voltage
• Existing nameplate
• Required output characteristics
• Physical mounting arrangement
• Product revision, where applicable

A clear photograph of the existing power supply nameplate can help identify the correct replacement.

TSXPSY1610M Reference

Schneider Electric currently identifies TSXPSY1610M as a Modicon Premium power supply module with 1500mA input current, 30W secondary power and a 19.2–30V DC input range. Schneider also lists a Modicon X80 BMXCPS2010 as a recommended replacement for TSXPSY1610M.

Because the TSX Premium platform and its components are legacy equipment, buyers should verify the exact reference required for their existing installation rather than assuming that a newer replacement has identical physical or electrical characteristics.

Official Schneider Electric Technical Reference

For additional specifications and technical information, refer to the official Schneider Electric TSXPSY1610M documentation.

This is an official Schneider Electric technical-documentation link and should remain a normal-follow outbound link in Elementor. Do not add nofollow to this link.

Used Modicon PLC Power Supply Replacement

Finding replacement components for older PLC installations can be difficult when the original automation platform is no longer actively marketed. A used or refurbished Modicon TSXPSY1610 Power Supply Unit can be considered for maintenance, repair and replacement requirements where the exact legacy configuration is required.

ZE MARINE can provide available product photographs and identification details for buyer verification, subject to current stock.

When requesting this product, please mention:

• TSXPSY1610 / TSX PSY 1610
• TSXPSY1610M, if shown on the nameplate
• Required quantity
• Existing PLC rack
• Application
• Nameplate photograph

Related Automation Products

ZE MARINE also supplies PLC, control and industrial automation equipment that may be relevant to Modicon Premium system maintenance:

• Modicon Momentum 170FNT11001 FIPIO Communication Adaptor
• Schneider Electric BMXAMI0810 Analog Input Module
• PLC Servo Drive
• PLC
• Siemens C7-623 Interface Module

Explore additional equipment in our Ship Automation Products category.

Used & Refurbished Automation Equipment from ZE MARINE

ZE MARINE supplies used, reusable and refurbished marine and industrial automation equipment for shipowners, ship managers, shipyards, marine engineers, repair companies and automation equipment traders.

Available equipment may include PLC power supplies, CPU modules, input and output modules, communication modules, control cards, automation panels and other electrical and control-system components.

Product condition and availability vary according to current stock. Buyers are encouraged to request photographs and technical identification details before ordering.

Request Price and Availability

For the Modicon TSX Premium TSXPSY1610 Power Supply Unit, contact ZE MARINE with your required quantity and existing PLC system details.

Manufacturer: Schneider Electric / Modicon
Product Family: Modicon Premium
Reference: TSX PSY 1610
Related Reference: TSXPSY1610M
Input: 24V DC nominal
Input Range: 19.2–30V DC
Typical Total Power: 30W
Condition: Used / Refurbished, subject to available stock

Contact ZE MARINE for current availability, photographs, price and shipping information.
